SHOP iSWISS
Unit of Measure
Technical Specs
Max Machining Diameter |
N/A 3/4 Inch |
Max Bar Length to Install |
N/A 20 Inch |
Machinable Length |
N/A 17 Inch |
Number of Tools |
N/A Front 5 tools (ID), Bottom 6 (OD), Top 2 (live) |
Max Drilling Capacity |
N/A 1/4 Inch |
Power Driven Tools |
N/A 2 |
Main Spindle Min. Indexing Degree |
N/A C-axis control 0.43 degrees resolution |
Main Spindle Speed |
N/A 1800 min-1 |
Main Spindle Motor |
N/A 300 W |
Rapid Feed Rate |
N/A 90 ipm |
Power-Driven att. Spindle Speed |
N/A 10000 rpm |
Power-Driven att. Drive Motor |
N/A 500W |
Coolant |
N/A Adjustable mist (coolant) on the point of machining (coolant tank not included) |
Dimensions |
N/A 14" x 29.5" Inch |
Weight |
N/A 150 lb |
Power |
N/A 120V standard wall outlet with proper grounding V |
Warranty |
N/A 3 Years |
